G1/2 Thread 24VDC 4-20mA Humidity and Temperature Sensor Dew Point Transducer SS304

Product Description

Features:
PCD02 α-Al2O3/SiO2 hybrid dielectric dew point sensor is the world's most advanced humidity sensor using the latest nanotechnology, featuring long-term stability, fast response and durability in extremely high/low humidity levels. It can be recovered even after exposure to liquid water. It can monitor both dew point and temperature with a Temperature Sensor provided. Proper use of the meter can provide lifelong reliability without recalibration. The superior performance of the sensor makes it an ideal choice for many industrial applications.
  • Patented drift-free α-Al2O3/SiO2 hybrid dielectric humidity sensor
  • Ultra-fast response time ensures safe and reliable monitoring
  • Very low hysteresis makes it capable of giving reliable reading during rapid humidity change

Applications: OEM equipment manufacture, petrochemical, power, electronics, pharmaceutical, industrial gas, heat treatment, metallurgy, textile, aerospace, high speed rail, atomic energy, meteorology, natural gas, drying equipment, medical treatment, injection molding and warehousing, etc.


Dew point range

DP range-80 to +20ºC dew point (available)
Output signal

Output4 to 20mA(typical)
Specification

Supply9VDC (6VDC to 12VDC)
Accuracy±2ºC dew point
Response time

5 sec to 63% (> -50ºCDP)
5 to 300 sec to 63% (< -50ºCDP)
Operating temp.0 to +50ºC
-30 to +50ºC (available)
Repeatability0.5ºC dew point
Operating pressure5MPa
15 MPa (available)
Pressure connectionG1/2'' (Customization available)
Housing materialStainless steel
Sensor protectionStainless steel weaving filter with pore sizes < 8μm
EMCAccording to IEC 61326-1



Components


   G1/2 Thread 24VDC 4-20mA Humidity and Temperature Sensor Dew Point Transducer SS304


Wire connection


   G1/2 Thread 24VDC 4-20mA Humidity and Temperature Sensor Dew Point Transducer SS304


Drawing


   G1/2 Thread 24VDC 4-20mA Humidity and Temperature Sensor Dew Point Transducer SS304

G1/2 Thread 24VDC 4-20mA Humidity and Temperature Sensor Dew Point Transducer SS304G1/2 Thread 24VDC 4-20mA Humidity and Temperature Sensor Dew Point Transducer SS304FAQ:
1.    Q: Are you manufacturer or trading company?
        A: We are manufacturer which focuses on Pressure Sensor for 33 years.
2.    Q: What international certificates do you have?
        A: ISO9001, CE, RoHS Certificated.
3.    Q: What is your production capacity?
        A: We produced 2000000 pieces pressure sensor in year 2017.
4.    Q: What is the lead time of your product?
        A: Stocks are available for some products. The typical lead time is 8~14 working days for product without customization.
       Note: lead time may vary base on different products. Please contact us for detailed lead time.
5.    Q: What is the warranty of your products?
       A: Our warranty time is 18 months after shipment.
6.    Q: Do you provide customized products?
       A: Yes, we can laser mark your logo, model and product information according to your requirement. We provide OEM and ODM service.



Contact us if you need more details on Dew Point Transducer. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Dew Point Transmitter、Dew Point Sensor. If these products fail to match your need, please contact us and we would like to provide relevant information.
